Specifications

Frameset

StemFelt Sprint, -6 °
HeadsetIS (NO.44)
Handlebar51, 54, 48, 48, 51, 54 cm: Devox DBar.C0 Aero 31.8 mm, 400 mm,
56, 58, 61, 56, 58, 61 cm: Devox DBar.C0 Aero 31.8 mm, 420 mm
bar tapeFelt VelvetGel tape with 3M reflective base and Felt Bubble-Tech F-Wing bar end plugs
SaddlePrologo Dimension 143 T4.0
Seat postFelt AeroRoad IL 2.0, 350 mm

Specifications may change depending on supply of parts to our factory. Please contact your local dealer for exact specifications of their stock.

Geometry

	51	54	56	58	61	48
(A) Top Tube Length	529 mm	543 mm	560 mm	580 mm	605 mm	509 mm
(B) Seat Tube Length	473 mm	502.5 mm	526 mm	553 mm	601 mm	441 mm
(C) Seat Tube Angle	74.4 °	73.5 °	73.5 °	73.5 °	73 °	74.3 °
(D) Head Tube Length	111 mm	130 mm	150 mm	167 mm	197.5 mm	97 mm
(E) Steering Angle	72.1 °	73 °	73.5 °	74 °	74 °	71 °
(F) Chain Stay Length	408 mm	410 mm	410 mm	410 mm	412 mm	408 mm
(G) Wheel Base	977 mm	980 mm	988 mm	1003 mm	1024 mm	974 mm
(H) Standover Height	734 mm	760 mm	780 mm	807 mm	845 mm	705 mm
(I) BB-Drop	70 mm	70 mm	70 mm	70 mm	70 mm	72 mm
(K) Fork Offset	47 mm	47 mm	43 mm	43 mm	43 mm	52 mm
(L) Stack	518 mm	539 mm	561 mm	579 mm	608 mm	501 mm
(M) Reach	381 mm	383 mm	394 mm	408 mm	419 mm	370 mm
(N) Stem Length	90 mm	100 mm	100 mm	110 mm	120 mm	90 mm
(O) Crank Length	170 mm	172.5 mm	172.5 mm	175 mm	175 mm	165 mm
